Fujikura 70R Plus

The Fujikura 70R+ ribbon splicer utilizes precision, fixed v-groove technology for splicing ribbon fiber up to 12 fibers, including single fibers. Incorporating the proven ruggedized features pioneered by Fujikura, the 70R+ has automated and enhanced user control features to increase splicing efficiency. A user-programmable, automated wind protector expedites the splicing process by automatically closing to initiate the splicing process and opening upon splice completion. These automated features reduce the steps needed to execute a splice resulting in greater splicing efficiencies. An auto-start “clamshell design” tube heater applies heat to both sides of the splice protection sleeve resulting in a 40-second shrink time for the 12-fiber ribbon. The result is a total splice process time of approximately 55 seconds! Ruggedness and durability are greatly enhanced by a mirror-less optical system and a "severe-impact resistant" monitor. An innovative transit case doubles as a built-in or mobile workstation. In an industry first, the 70R+ is also equipped with Bluetooth® technology. This allows the splicer to actively communicate with Bluetooth enabled fiber preparation accessories making maintenance of fiber preparation tools easier than ever!

Features:

• Bluetooth wireless communication
• Automated and programmable wind protector
• 40-second automated tube heater
• Fully ruggedized for shock, dust and moisture
• Li-ion battery with 110 splices/shrinks per charge
• On-board training and support videos
• Multi-function transit case with integrated workstation
